Product Description
Powerful Tractor Pole Drilling Machine in Malawi
Tractor: YTO tractor(famous brand)
Drilling depth:0-6m
Drilling diameter: 300mm-2000mm
Standard drill pipe: 300mm-500mm (can customize 500~1200mm drill pipes)
Lift way: Hydraulic
Standard drilling time: 50s (diameter of 300mm-500mm)
Application: loess, clay, pebble sand, weathered granite, tundra etc.
Not suitable for: rocks, whole sand bed ,household garbage and so on.
Operator needed: 1 person
Technical Parameters
| Model |
BS-850 |
BS-1004 |
BS-1004H |
| Drive type |
4*2 |
4*4 |
4*4 |
| Power |
85HP |
100HP |
110HP |
| Steering system |
Hydraulic system |
Hydraulic system |
Hydraulic system |
| Bit material |
Alloy steel |
Alloy steel |
Alloy steel |
| Drill pipe reamer material |
Manganese steel |
Manganese steel |
Manganese steel |
| Hole diameter(mm) |
100-2000 |
100-2000 |
100-2000 |
| Hole depth(mm) |
100-6000 |
100-6000 |
100-6000 |
| Overall size(L*W*H) mm |
5520*2100*2884 |
6520*2170*2894 |
7520*2170*2994 |
| Weight(T) |
6.5 |
6.8 |
7.1 |
| Hoisting machine |
3T, 5T, 8T |
5T, 8T, 10T |
8T, 10T, 12T |
| Dig a pit speed(/sec) |
25-60 |
25-60 |
25-60 |
Widely Application
This kind of machine is fastest method to dig up hole as it is driven by P.T.O, which can can dig up to the depth of 5.5 feet depending up on the soil properties,
and widely useful for plantation & fencing, digging pits to plant mango, coconut, sugarcane (Pith system cultivation), Teak, Pomegranate, etc.
Product Photos
Delivery Photos
Our Services
1.Professional service and product knowledge
2.We keep the service philosophy: think what customer cares, do what client wants.
3.Professional service after-sale will be offered.
4.Good price and high quality.
5.We're a trusted cooperated group!
