OEM tractor crane for tractor mounted post hole digger machine

OEM tractor crane for tractor mounted post hole digger machine

    • OEM tractor crane for tractor mounted post hole digger machine
    • OEM tractor crane for tractor mounted post hole digger machine
    • OEM tractor crane for tractor mounted post hole digger machine
    • OEM tractor crane for tractor mounted post hole digger machine
    • OEM tractor crane for tractor mounted post hole digger machine
    • OEM tractor crane for tractor mounted post hole digger machine
  • OEM tractor crane for tractor mounted post hole digger machine

    Product Details:

    Place of Origin: China
    Brand Name: BAISHUN
    Certification: ISO9001:2008; CE.
    Model Number: BS-1004

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD22000-45000 / SET
    Packaging Details: Export standard package
    Supply Ability: 600 sets/month
    Contact Now
    Detailed Product Description
    Model Number: BS-1004 Color: Customer's Request
    Drilling Diameter: 2M Drilling Depth: 100-6000MM
    Power: 100HP OEM: Yes
    Bit Material: Alloy Steel Weight: 7000KGS
    Warranty: 12 Months

    Production Description



    OEM tractor crane for tractor mounted post hole digger machine

    Machine is widely used to plant big plants and to erect electricity and solar poles, the electric power,communication, municipal, railway, highway, construction, petroleum, trees, such as the ideal foundation construction equipment


    Technical Parameters

    Tractor:Different YTO tractors(famous brand)

    Drilling depth: 0-6m
    Drilling diameter: 300mm-2000mm

    Lifting capability of crane: 3~8tons

    Length of pole: 3~18m
    Standard drill pipe: 300mm-500mm (can customize 500~2000mm drill pipes)
    Crane Lifting way: Hydraulic
    Standard drilling time: 50s (diameter of 300mm-500mm)
    Application: loess, clay, pebble sand, weathered granite, tundra etc.
    Not suitable for: rocks, whole sand bed ,household garbage and so on.
    Operator needed:1 person



    Technical Features

    1. Have four hydraulic stabilizer legs, with cross-country 2 or 4 wheel-drive, with wide tires

    2. 360° rotation gear motor, hydraulic hoisting and drilling system, combining the auger drill rig with crane, one equipment can realize the drilling and pole uprighting work, more efficient and cost-effective.



    3. YTO tractor as power, strong enough , strong cross-country power. Fully hydraulic driving. Full-automatic put and upright the pole.




    Some Photos for Your Reference
    OEM tractor crane for tractor mounted post hole digger machine



    OEM tractor crane for tractor mounted post hole digger machineOEM tractor crane for tractor mounted post hole digger machineOEM tractor crane for tractor mounted post hole digger machineOEM tractor crane for tractor mounted post hole digger machineOEM tractor crane for tractor mounted post hole digger machine



    Delivery Features

    OEM tractor crane for tractor mounted post hole digger machineOEM tractor crane for tractor mounted post hole digger machineOEM tractor crane for tractor mounted post hole digger machineOEM tractor crane for tractor mounted post hole digger machine
